Carrier-Trizeps-pConXS
SECO Carrier-Trizeps-pConXS is a very compact and multifunctional carrier board for Trizeps SODIMM SOMs, designed to support evaluation, bring-up and system integration across compatible Trizeps platforms including Trizeps VII, Trizeps VIII, Trizeps VIII Mini, Trizeps VIII Nano and Trizeps VIII Plus.
On the display and vision stack, it supports HDMI, LVDS, Dual LVDS and RGB display interfaces, enabling integration of different touch displays, and also includes both analog BNC or Mini BNC parallel camera interface options plus a MIPI camera connector.
For connectivity and expansion, the board provides Gigabit Ethernet, USB 2.0 Host, USB 2.0 OTG, USB 2.0 touch interface, a Mini PCIe Half or Full Size connector combined with nano SIM slot, SD card socket, RS232 via D-SUB, additional UARTs on header, stereo audio jack, digital microphone connector, SATA II, I2C extension header, GPIO, SPDIF, 2x CAN, SDIO and ADC signals on the 40 pin extension connector.
For system integration, it supports Linux Yocto, Linux Debian, Android and Windows 10 IoT, accepts industrial 12V to 24V power input, operates from -20°C to +85°C, and comes in a compact 118.5 mm x 84.0 mm x 43.0 mm format.
Technical Documents
At the following Links you will find documentations like Manual and Rev. specific documents.
