Titan 220 APL Med (SYS-D14-MED)
Depending on the configuration and following revisions, the features of thecboard are subject to change. For detailed information on hardwarecspecifications, please visitc www.seco.com
SECO Titan 220 APL Med is a boxed gateway (DRACO, SYS-D14-MED) positioned for medical application scenarios, based on Intel® Atom™ x5-E3930 processors and designed as a compact platform for early integration and field connectivity.
On the connectivity and expansion stack, it provides 2x USB 3.0 Type-A on the front panel, an M.2 Socket 1 Key E slot for WiFi and Bluetooth modules, and an internal microSIM slot (noted as connected to the internal M.2 area).
For deployment constraints, the page specifies a DC power jack with recommended +18VDC to +32VDC input (absolute +15VDC to +36VDC), an operating temperature of 0°C to +40°C (in presence of air flow), and mechanical dimensions of 162.3 x 109.3 x 42.4 mm.
For ordering purposes, Titan 220 APL Med is referred to by its base code, "SYS-D14-MED".
Technical Documents
At the following Links you will find documentations like Manual and Rev. specific documents.
Manual
Datasheet
Product page
Connect to Clea Cloud
Step by step guide to register a Clea OS device and configure endpoints and credentials to enable cloud connectivity and device management.
What is loaded in a standard module?
Off-the-shelf products are shipped with a standard in-house-developed software. The definition of standard, in this case, is “the environment which SECO adopts for validation”. Anyway, custom in-house-developed software with different defaults can be built. Contact your reference sales for further information.
Clea OS
All off-the-shelf products are shipped with Clea OS preinstalled as the standard software environment. Clea OS is a versatile and robust Linux Operating System framework designed specifically for industrial embedded devices. Based on the open source Yocto Project, Clea OS offers a flexible and customizable platform that can be tailored to meet the specific needs of various hardware architectures and applications.
Starting with Linux Kernel 6.6, the Board Support Package (BSP) for this board is fully integrated into Clea OS. It ensures high security and stability through features like OTA (Over-the-Air) updates, dual partitions, and fallback procedures. Additionally, Clea OS includes a complete device manager for seamless cloud communication, enabling centralized management of product fleets.
Documentation
For a complete explanation of Clea OS and detailed installation instructions, refer to the official documentation:
Download Clea OS Images
To quickly get started, download the latest complete prebuild Clea OS images (or other binaries like U-Boot, Linux Kernel, SDKs) from the official release page:
Build Clea OS
The source code for Clea OS can be found at the following Gitlab organization. To build a complete BSP image from source you can check the Get Started pages of the documentation.
